Plain Dutch Weave Stainless Steel Wire Mesh
Plain Dutch weave, also called mat weave, uses vertical (warp) wires that are thicker than the horizontal (weft) wires. The number of warp wires per inch is limited, while as many weft wires as possible are packed tightly together, giving a very strong structure. Liquid passes between the warp and weft wires, so the mesh combines strength with fine filtration.
Specifications
All sizes in grade 304. Wire diameters are given as warp / weft.
| Mesh number | Wire diameter (mm) | Approx. aperture (µm) |
|---|---|---|
| 12 × 72 | 0.45 / 0.40 | 265–285 |
| 14 × 88 | 0.40 / 0.30 | 255–275 |
| 24 × 110 | 0.35 / 0.25 | 115–128 |
| 30 × 150 | 0.23 / 0.18 | 90–105 |
| 40 × 200 | 0.18 / 0.14 | 70–80 |
| 50 × 250 | 0.14 / 0.11 | 52–57 |
| 80 × 400 | 0.12 / 0.08 | 40–45 |
Need a mesh number or wire diameter that is not listed? Please ask our sales team.
Applications
FAQ
How is the mesh number of wire mesh measured?
Count the openings along one inch. Twenty openings means mesh 20.
What is the difference between grades 304 and 316?
Grade 304 is the most widely used and suits most applications. Grade 316 resists acids and alkalis better, which suits coastal areas, food, pharmaceuticals and chemicals.
When will I receive my order?
Rolls within 3–5 working days; cut or finished products within 10 working days.
